Welltech Technology Co., Ltd. Released Version 1.0

WPoE-808 PoE Ethernet Switch Installation Guide

Content

1. Accessories ........................................................................................................................ 1

2. LED Indication on front panel ........................................................................................... 2

3. Installation ......................................................................................................................... 3

1. Accessories

Before starting to install PoE Ethernet Switch, please check the following accessories

within package you have received at Figure 1.

Figure 1.

Item 1: Main unit of WPoE-808 Ethernet 8 ports Switch.

Item 2: AC 100 to 230V power cable with one of US, Europe or UK Type AC Plug

ping depend on your country specification.

Item3: 19-inch rack mount bracket x 2 pcs.

Item 4: Desk top foot pads and screw to fix bracket on main unit.

1 2 3

1 Welltech Technology Co., Ltd. Released Version 1.0 WPoE-808 PoE Ethernet Switch Installation Guide Content 1. Accessories ...

2 Welltech Technology Co., Ltd. Released Version 1.0 2. LED Indication on front panel Figure 2. PWR

3 Welltech Technology Co., Ltd. Released Version 1.0 3. Installation Figure 3. Make sure to follow above photo’s three st
